PD-GM-04 Magnesium Aluminum Zinc steel material suitable for large scale solar ground screw mounting system, or solar park ground mount pv racking systems
PD-GM-04
Ground Clearance:200mm-800mm
Tilt Angle:10-40°
Wind Speed: 0-60m/s
Snow Load:0-150cm
Preformance:High Corrosion Resistance
Drawing: Available
Strength Report: Available
About Panda solar Magnesium Aluminum Zinc Ground Mounting Systems For Solar Panels：
GM4 is a design of No.4 ground brackets developed by Pandasolarpv. It uses magnesium aluminum zinc material and double-column structure, solar panel racking system ground mount can meet the requirements of hlandscape and portrait solar panels. Reducing the shading at the bottom of the solar panel is the maximum power output of the solar panel.
GM4 double column can be ground bolt column or piling column,Ground screw posts allow for tiny height adjustments
The piling column strength is higher, and the requirements for installation accuracy are also higher.
Structural features:
|
Material |
Structure:Mg-Al-Zn &AL-6005-T5 (Anodized） Components: SUS304 & AI6005-5(Anodized） |
|
Application |
Commercial and Residential installation |
|
Tilt Angle |
0-60° |
|
Wind Speed |
0-60 m/s |
|
Snow Load |
0-150cm |
|
Ground Clearance |
0-1m |
|
Design Standard |
AS/NZS 1170, DIN 1055, JIS C8955: 2017, International Building Code IBC 2009 |
|
Warranty |
12 years |
PACKING & SHIPPING
Certificate:
CE test for all solar mounting components
Workshop-Aluminum Material：
PandaSolar has a professional aluminum alloy product processing workshop, cutting, drilling, stamping, forging and other work are completed independently.
Professional production team can accept products with high customization/precision requirements.
Workshop-Steel Material：
PandaSolar has a professional steel/Magnesium aluminum zinc/S350GD/S450GD processing workshop as well, 6 production lines, and several molding machines. According to different projects, it can complete cutting and holes processing, with productivity of 40-50MW per month.
FAQ:
♥: What's your delivery time?
A: 12days
♥: Can you send the samples?
A: Yes, free samples for your test.
♥: Are you manufacture?
A: Yes, Our production experience is more than 12 years.
♥: Do you have OEM service?
A: Yes, we accept OEM service.
♥: How can I get the best price?
A: Send an inquiry to us and a professional will quote you.
